Marina ECM 75-DS Drainage pump

APPLICATIONS
Cast iron submersible drainage pumps, suitable for dirty or waste water in civil and industrial systems, including liquids with suspended solids, on building sites and in agriculture.

LIMITS OF USE
- Liquid temperature up to 35°C (domestic use according to EN 60335-2-41)
- Max. liquid temperature 35°C (other uses)
- Maximum immersion depth 10 m
- Minimum suction level 100 mm
- Continuous duty

MOTOR
- Single-phase 230V 50Hz with float switch
- Built-in thermal protection
- Insulation class F
- IP 68 protection

MATERIALS
- Motor body: Cast iron
- Pump body: Cast iron
- Impeller: Cast iron
- Motor shaft: AISI 304 stainless steel
- Suction strainer: AISI 304 stainless steel
- Mechanical seal in oil chamber: Silicon/Silicon/NBR

TECHNICAL DATA Marina ECM 75-DS
- Power supply: single-phase 230V 50Hz
- Rated power: 0.75 HP (0.55 kW)
- Power input P1: 0.9 kW
- Max. flow rate: 350 l/min
- Max. head: 10 m
- Delivery port: 1" 1/2
- Weight: 17.3 kg
