Marina TRIPLEX 500 Drainage pump

APPLICATIONS
Submersible electric pumps with interchangeable suction bases for multiple uses: without base they drain down to 1 mm, with base 1 for clean water and with base 2 for dirty water. Suitable for quick and efficient draining of pools, flooded cellars and ponds.

LIMITS OF USE
- Liquid temperature up to 35°C (domestic use according to EN 60335-2-41)
- Max. liquid temperature 35°C (other uses)
- Maximum immersion depth 5 m
- Minimum suction level 1 mm

MOTOR
- Single-phase 230V 50Hz with float switch
- Built-in automatic reset overload protection
- Permanent capacitor fitted
- Insulation class F
- IP 68 protection
- Power cable 10 m

MATERIALS
- Handle: Polypropylene
- Pump body: Polypropylene
- Impeller: Noryl
- Motor casing: Stainless steel
- Motor shaft: Stainless steel
- Lubricated mechanical seal

TECHNICAL DATA Marina TRIPLEX 500
- Power supply: single-phase 230V 50Hz
- Power input P1: 0.5 kW
- Max. flow rate: 160 l/min
- Max. head: 6.5 m
- Delivery port: 1" 1/4
- Weight: 5 kg
